ตัวขยาย HDMI Extender RJ45 (Cat5e,Cat6) 50M With IR POE

Features

1.Allows HDMI Audio/Video and IR signals to be transmitted over a single Cat5e/6 cable.
2.Support copy EDID from receiver display or loop out display.
3.Allows for cascading via additional HDMI loop out port.
4.Support power over cable function.
5.Transmission Range:Extends 1080p resolution up to 164ft/50m over a single Cat5e or Cat6 cable.
6.Works with HDMI and HDCP compliant devices.
7.Support up to 1080p High definition resolution.
8.Conpact design for an easy and flexible installation.

Specifications

• Video Bandwidth:Single-link 165Mhz[4.95Gbps]
• Video Support:480i/480p/720p/1080i/1080p @60Hz
• Audio Support:Surround Sound(up to 7.1ch)or stereo digital audio
• Transmission Range:HD 1080p 24 bit color up to 164ft
• Input TMDS Signal:3.3 volts
• Input DDC signal:5.0 volts/P-P
• ESD Protection:Human Body model: /-8KV(air-gap discharge)  /-4KV(contact discharge)
• HDMI connector:Type A 19 pin female
• RJ-45 connector:WE/SS 8P8C
• 3.5mm connector:(TX&RX)IR Receiver/IR Blaster

Package Contents

• HDMI Transmitter----------------------1pcs
• HDMI Receiver--------------------------1pcs
• Windband IR Tx cable-----------------1pcs
• windband IR Rx cable-----------------1pcs
• 5V1A DC Power Supply Adaptor-----1pcs
• Product Manual-------------------------1pcs
